CC1150

SWRS037A

Page 45 of 60

25.1

Configuration Register Details

0x01: IOCFG1 – GDO1 output pin configuration

Bit

Field Name

Reset

R/W

Description

GDO_DS

R/W

Set high (1) or low (0) output drive strength on the

GDO pins.

GDO1

_INV

R/W

Invert output, i.e. select active low (1) / high (0).

5:0

GDO1

_CFG[5:0]

46 (0x2E)

R/W

Default is tri-state (See Table 24 on page 38).

0x02: IOCFG0 – GDO0 output pin configuration

Bit

Field Name

Reset

R/W

Description

TEMP_SENSOR_ENABLE

R/W

Enable analog temperature sensor. Write 0 in all other

GDO0

_INV

R/W

Invert output, i.e. select active low (1) / high (0).

5:0

GDO0

_CFG[5:0]

63 (0x3F)

R/W

Default is CLK_XOSC/192 (See Table 24 on page 38).

It is recommended to disable the clock output during

initialization in order to optimize RF performance.

0x03: FIFOTHR – FIFO threshold

Bit

Field Name

Reset

R/W

Description

7:4

Reserved

R/W

Write 0 for compatibility with possible future

extensions.

3:0

FIFO_THR[3:0]

7 (0x07)

R/W

Set the threshold for the TX FIFO. The threshold is

exceeded when the number of bytes in the FIFO is

equal to or higher than the threshold value.

Setting

Bytes in TX FIFO

0 (0000)

1 (0001)

2 (0010)

3 (0011)

4 (0100)

5 (0101)

6 (0110)

7 (0111)

8 (1000)

9 (1001)

10 (1010)

11 (1011)

12 (1100)

13 (1101)

14 (1110)

15 (1111)
