10 / 60 page ![]() ADP5050 Data Sheet Rev. 0 | Page 10 of 60 ABSOLUTE MAXIMUM RATINGS Table 5. Parameter Rating PVIN1 to PGND −0.3 V to +18 V PVIN2 to PGND −0.3 V to +18 V PVIN3 to PGND3 −0.3 V to +18 V PVIN4 to PGND4 −0.3 V to +18 V PVIN5 to GND −0.3 V to +6.5 V SW1 to PGND −0.3 V to +18 V SW2 to PGND −0.3 V to +18 V SW3 to PGND3 −0.3 V to +18 V SW4 to PGND4 −0.3 V to +18 V PGND to GND −0.3 V to +0.3 V PGND3 to GND −0.3 V to +0.3 V PGND4 to GND −0.3 V to +0.3 V BST1 to SW1 −0.3 V to +6.5 V BST2 to SW2 −0.3 V to +6.5 V BST3 to SW3 −0.3 V to +6.5 V BST4 to SW4 −0.3 V to +6.5 V DL1 to PGND −0.3 V to +6.5 V DL2 to PGND −0.3 V to +6.5 V SS12, SS34 to GND −0.3 V to +6.5 V EN1, EN2, EN3, EN4, EN5 to GND −0.3 V to +6.5 V VREG to GND −0.3 V to +6.5 V SYNC/MODE to GND −0.3 V to +6.5 V VOUT5, FB5 to GND −0.3 V to +6.5 V RT to GND −0.3 V to +3.6 V nINT, PWRGD to GND −0.3 V to +6.5 V FB1, FB2, FB3, FB4 to GND1 −0.3 V to +3.6 V FB2 to GND2 −0.3 V to +6.5 V FB4 to GND2 −0.3 V to +7 V COMP1, COMP2, COMP3, COMP4 to GND −0.3 V to +3.6 V VDD, VDDIO to GND −0.3 V to +3.6 V SCL, SDA −0.3 V to VDDIO + 0.3 V Storage Temperate Range −65°C to +150°C Operational Junction Temperature Range −40°C to +125°C 1 This rating applies to the adjustable output voltage models of the ADP5050. 2 This rating applies to the fixed output voltage models of the ADP5050. Stresses above those listed under Absolute Maximum Ratings may cause permanent damage to the device. This is a stress rating only; functional operation of the device at these or any other conditions above those indicated in the operational section of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability. THERMAL RESISTANCE θJA is specified for the worst-case conditions, that is, a device soldered in a circuit board for surface-mount packages. Table 6. Thermal Resistance Package Type θJA θJC Unit 48-Lead LFCSP 27.87 2.99 °C/W ESD CAUTION |
|
