Data Sheet

ADP5050

Rev. 0 | Page 53 of 60

Register 15 is used to mask or unmask various warnings for use by the interrupt (nINT) pin. When any bit in this register is masked, the

associated event does not trigger the nINT pin.

Table 47. Register 15 Bit Assignments

Bit 7

Bit 6

Bit 5

Bit 4

Bit 3

Bit 2

Bit 1

Bit 0

Reserved

MASK_TEMP

MASK_LVIN

MASK_PWRG4

MASK_PWRG3

MASK_PWRG2

MASK_PWRG1

Table 48. INT_MASK Register, Bit Function Descriptions

Bits

Bit Name

Access

Description

[7:6]

Reserved

R/W

Reserved.

MASK_TEMP

R/W

0 = temperature overheat warning does not trigger the interrupt pin (default).

1 = temperature overheat warning triggers the interrupt pin.

MASK_LVIN

R/W

0 = low voltage input warning does not trigger the interrupt pin (default).

1 = low voltage input warning triggers the interrupt pin.

MASK_PWRG4

R/W

0 = power-good warning on Channel 4 does not trigger the interrupt pin (default).

1 = power-good warning on Channel 4 triggers the interrupt pin.

MASK_PWRG3

R/W

0 = power-good warning on Channel 3 does not trigger the interrupt pin (default).

1 = power-good warning on Channel 3 triggers the interrupt pin.

MASK_PWRG2

R/W

0 = power-good warning on Channel 2 does not trigger the interrupt pin (default).

1 = power-good warning on Channel 2 triggers the interrupt pin.

MASK_PWRG1

R/W

0 = power-good warning on Channel 1 does not trigger the interrupt pin (default).

1 = power-good warning on Channel 1 triggers the interrupt pin.

The write-only Register 17 is used to reset all registers to their default values.

Table 49. Register 17 Bit Assignments

Bit 7

Bit 6

Bit 5

Bit 4

Bit 3

Bit 2

Bit 1

Bit 0

DEFAULT_SET[7:0]

Table 50. DEFAULT_SET Register, Bit Function Descriptions

Bits

Bit Name

Access

Description

[7:0]

DEFAULT_SET[7:0]

To reset all registers to their default values, write 0x7F to this register.
