44 / 60 page ![]() ADP5050 Data Sheet Rev. 0 | Page 44 of 60 REGISTER 5: DVS_CFG (DVS CONFIGURATION FOR CHANNEL 1 AND CHANNEL 4), ADDRESS 0x05 Register 5 is used to configure dynamic voltage scaling (DVS) for Channel 1 and Channel 4 (see the Dynamic Voltage Scaling (DVS) section). Table 27. Register 5 Bit Assignments Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Reserved DVS4_ON DVS4_INTVAL[1:0] Reserved DVS1_ON DVS1_INTVAL[1:0] Table 28. DVS_CFG Register, Bit Function Descriptions Bits Bit Name Access Description 7 Reserved R/W Reserved. 6 DVS4_ON R/W 0 = disable DVS for Channel 4 (default). 1 = enable DVS for Channel 4. [5:4] DVS4_INTVAL[1:0] R/W These bits configure the DVS interval for Channel 4. 00 = 62.5 µs (default). 01 = 31.2 µs. 10 = 15.6 µs. 11 = 7.8 µs. 3 Reserved R/W Reserved. 2 DVS1_ON R/W 0 = disable DVS for Channel 1 (default). 1 = enable DVS for Channel 1. [1:0] DVS1_INTVAL[1:0] R/W These bits configure the DVS interval for Channel 1. 00 = 62.5 µs (default). 01 = 31.2 µs. 10 = 15.6 µs. 11 = 7.8 µs. |
|
