ADP5050

Data Sheet

Rev. 0 | Page 52 of 60

READBACK), ADDRESS 0x0E

junction temperature overheat warning, low input voltage warn-

ing, and power-good signal failure on Channel 1 to Channel 4.

When any of these unmasked events occur, the nINT pin is

pulled low to indicate a fault condition. (Masking of these events

is configured in Register 15.) To determine the cause of the fault,

read this register. Latched flags are not reset when the fault dis-

appears but are cleared only when a 1 is written to the appropriate

bit or when all ENx pins = 0.

Table 45. Register 14 Bit Assignments

Bit 7

Bit 6

Bit 5

Bit 4

Bit 3

Bit 2

Bit 1

Bit 0

Reserved

TEMP_INT

LVIN_INT

PWRG4_INT

PWRG3_INT

PWRG2_INT

PWRG1_INT

Table 46. INT_STATUS Register, Bit Function Descriptions

Bits

Bit Name

Access

Description

[7:6]

Reserved

R/W

Reserved.

TEMP_INT

Read/

self-clear

This bit indicates whether the junction temperature threshold has been exceeded.

0 = junction temperature has not exceeded the threshold.

1 = junction temperature has exceeded the threshold.

LVIN_INT

Read/

self-clear

This bit indicates whether the low voltage input threshold has been exceeded.

0 = low voltage input has not fallen below the threshold.

1 = low voltage input has fallen below the threshold.

PWRG4_INT

Read/

self-clear

The power-good interrupt is masked when the part is initialized and during a normal shutdown.

0 = no power-good failure has been detected on Channel 4.

1 = power-good failure has been detected on Channel 4.

PWRG3_INT

Read/

self-clear

The power-good interrupt is masked when the part is initialized and during a normal shutdown.

0 = no power-good failure has been detected on Channel 3.

1 = power-good failure has been detected on Channel 3.

PWRG2_INT

Read/

self-clear

The power-good interrupt is masked when the part is initialized and during a normal shutdown.

0 = no power-good failure has been detected on Channel 2.

1 = power-good failure has been detected on Channel 2.

PWRG1_INT

Read/

self-clear

The power-good interrupt is masked when the part is initialized and during a normal shutdown.

0 = no power-good failure has been detected on Channel 1.

1 = power-good failure has been detected on Channel 1.
