background image
Table 10. Power supply specifications for VDDE_1V8
Symbol
Parameter
Test conditions
Typ.
Max.
Unit
IDDPD
VDD supply current
in Power down
mode
VDD = max; PDN <
VIL
1
50
µA
IDDBYPASS
VDD supply current
in Bypass mode
VDD = max; image
format = RAW8;
input/ouput data
rate = 1.6 Gbps
CSI dual
11
15
mA
IDDNORMAL
VDD supply current
in Normal mode
VDD = max; CCP
RAW10 640 Mbps
11
25
VDD = max; CSI
single RAW10 800
Mbps
12
25
VDD = max; CSI
dual RAW12 1.6
Gbps
18
30
Table 11. CCP2 class 2 receiver electrical characteristics
For further information on CCP2, please refer to the SMIA 1.0 Part 2: CCP2 Specification Available from http://
www.smiaforum.org
Symbol
Parameter
Test conditions
Min.
Typ.
Max.
Unit
VCMI_SMIA
Input common
mode voltage
range
Embedded RTI
= 100 Ω ± 10 %
0.65
0.95
1.15
V
VIDTH_SMIA
Input differential
threshold (VP -
VN)
±50
±200
mV
tPWRUP/tPWRDN
Power up/-down
time
20
µs
RTI
Embedded
termination
resistance
80
100
125
Ω
11.5
AC electrical characteristics
11.5.1
EXTCLK
VEXTCLKAC and VEXTCLKDC are defined in Table 8. I/O electrical characteristics
Table 12. EXTCLK electrical characteristics
Symbol
Parameter
Min.
Typ.
Max.
Unit
fEXTCLK
Clock frequency
input, 50 % duty
cycle - VDDE_1V8
referred
6
13
27
MHz
STMIPID02
AC electrical characteristics
DS12803 - Rev 1
page 37/50
