 3 / 50 page
background image
1
Block diagram
Figure 1. Block diagram
SCL
SDA
EXTCLK
CLKP1
CLKN1
DATA1P1
DATA1N1
D[11:0]
VSYNC
ERROR
INT
I2C
slave
SMIA CCP2 RX
Clock
MIPI CSI-2 RX
STMIPID02
Slave clock lane module
manager
400kHz
1.2V voltage
regulator (LDO)
JTAG
controller
Clock recovery &
de-serializer
Clock lane
control
interface
logic
Slave data lane module
Data lane
control
interface
logic
MIPI D-PHY RX
Protocol
DATA2P1
DATA2N1
Data Lane 1.2
80-800Mbps
Data Lane 1.1
80-800Mbps
Clock Lane 1
40-400MHz
HSYNC
PCLK (up to 200MHz)
Power
on
reset
VDDOUT_LDO
6.0MHz - 27MHz
1V8 12-bit parallel
interface @ 200MHz
1V8
Doubles
as CCP2
data &
clock/strobe
inputs
XSDN
Slave data lane module
Data lane
control
interface
logic
CLKP2
CLKN2
DATA1P2
DATA1N2
Slave clock lane module
Clock lane
control
interface
logic
Data Lane 2
80-800Mbps
Clock Lane 2
40-400MHz
Slave data lane module
Data lane
control
interface
logic
Doubles
as CCP2
data &
clock/strobe
inputs
STMIPID02
Block diagram
DS12803 - Rev 1
page 3/50
