4
Control interface
The STMIPID02 is controlled through the 400 kHz I2C compatible slave command interface. The 8-bit device
address is 0x28 for write operations and 0x29 for read operations. The register index is a 16-bit format and the
register value is an 8-bit format. The external clock must be active for I2C slave operations.
Example
To write 0x15 in the register 0x02, the following sequence has to be applied:
S 0x28 A 0x00 A 0x02 A 0x15 A
To read the content of register 0x02:
S 0x28 A 0x00 A 0x02 A P S 0x29 A xx N P
Where S = START; P = STOP; A = ACK; N = NACK
Detailed control inteface timings are described in Section 11.5.2 I2C slave timing (SCL, SDA).
STMIPID02
Control interface
DS12803 - Rev 1
page 7/50
