ADP5020
Rev. 0 | Page 23 of 2
8
LAYOUT RECOMMENDATIONS
APPLICATIONS SCHEMATIC
VBATT
VDD1
VDD2
VDD3
VDDA
VDD_IO
SDA
SCL
SYNC
EN/GPIO
DGND
AGND
XSHTDN
VOUT3
PGND2
PGND1
VOUT2
VOUT1
VOUT1
SW2
C4
10µF
C6
1.0µF
C2
4.7µF
C1
10µF
C3
1.0µF
C5
0.1µF
R1
10kΩ
R2
10kΩ
L1
2.2µH
L2
2.2µH
ADP5020
+VIS
–VIS
+VCORE
–VCORE
+VIO
–VIO
GND
VDDIO
SDA
SCL
SYNC
XSHTDN
GPIO/EN
SW1
Figure 29. Schematic for Camera Module Applications
