background image
E5EC/E5EC-B/E5AC
43
Optional Products (Order Separately)
USB-Serial Conversion Cable
Communications Conversion Cable
Note: Always use this product together with the E58-CIFQ2.
This Cable is used to connect to the front-panel Setup Tool
port.
Terminal Covers (for E5EC/E5AC)
Note: The Terminal Covers E53-COV24 are provided with the Digital
Temperature Controller.
Waterproof Packing
Note: This Waterproof Packing is provided with the Digital
Temperature Controller.
Waterproof Cover
Front Port Cover
Note: This Front Port Cover is provided with the Digital Temperature
Controller.
Mounting Adapter
Note: This Mounting Adapter is provided with the Digital Temperature
Controller.
Current Transformers (CTs)
* Lead wires are included with these CTs. If UL certification is
required, use these CTs.
CX-Thermo Support Software
Note: CX-Thermo version 4.5 or higher is required for the E5EC/
E5AC.
CX-Thermo version 4.65 or higher is required for the E5EC-B.
CX-Thermo version 4.67 or higher is required for the E5CC-B
linear current output type.
For the system requirements for the CX-Thermo, refer to
information on the EST2-2C-MV4 on the OMRON website
(www.ia.omron.com).
Model
E58-CIFQ2
Model
E58-CIFQ2-E
Model
E53-COV24 (3pcs)
Applicable Controller
Model
E5EC/E5EC-B
Y92S-P9
E5AC
Y92S-P10
Applicable Controller
Model
E5EC/E5EC-B
Y92A-49N
E5AC
Y92A-96N
Model
Y92S-P7
Model
Y92F-51 (2pcs)
Hole diameter
Model
5.8 mm
E54-CT1
5.8 mm
E54-CT1L
*
12.0 mm
E54-CT3
12.0 mm
E54-CT3L
*
Model
EST2-2C-MV4
