Characteristics

*1. The indication accuracy of K thermocouples in the −200 to 1,300°C range, T and N thermocouples at a temperature of −100°C max., and U

and L thermocouples at any temperature is

±2°C ±1 digit max. The indication accuracy of B thermocouples at a temperature of 400°C max. is

not specified. The indication accuracy of B thermocouples at a temperature of 400 to 800

°C is ±3°C max.

The indication accuracy of R and S thermocouples at a temperature of 200

°C max. is ±3°C ±1 digit max. The indication accuracy of C/W

thermocouples is (

±0.3% of PV or ±3°C, whichever is greater) ±1 digit max.

The indication accuracy of PLII thermocouples is (

±0.3% of PV or ±2°C, whichever is greater) ±1 digit max.

*2. However, the precision between 0 and 4 mA for a 0 to 20 mA output is ±1% FS max.

*3. Ambient temperature: −10°C to 23°C to 55°C, Voltage range: −15% to 10% of rated voltage

*4. K thermocouple at −100°C max.: ±10°C max.

*5. The unit is determined by the setting of the Integral/Derivative Time Unit parameter.

*6. External serial communications (RS-485) and USB-Serial Conversion Cable communications can be used at the same time.

*7. Refer to your OMRON website for the most recent information on applicable models.

*8. Refer to information on maritime standards in Shipping Standards on page 124 for compliance with Lloyd's Standards.

*9. Industrial electromagnetic environment (EN/IEC 61326-1 Table 2)

Indication accuracy

(when mounted individually,

ambient temperature of 23

°C)

Thermocouple: (

±0.3 % of indication value or ±1°C, whichever is greater) ±1 digit max.*1

Platinum resistance thermometer: (

±0.2 % of indication value or ±0.8°C, whichever is greater) ±1 digit max.

Analog input:

±0.2% FS ±1 digit max.

CT input:

±5% FS ±1 digit max.

Simple transfer output accuracy

±0.3% FS max.*2

Influence of temperature

Thermocouple input (R, S, B, C/W, PL II): (

±1% of indication value or ±10°C, whichever is greater) ±1 digit max.

Other thermocouple input: (

±1% of indication value or ±4°C, whichever is greater) ±1 digit max. *4

Platinum resistance thermometer: (

±1% of indication value or ±2°C, whichever is greater) ±1 digit max.

Analog input:

±1% FS ±1 digit max.

CT input:

±5% FS ±1 digit max.

Influence of voltage

Influence of EMS. (at EN 61326-1)

Installation influence (E5DC only) R, S, B, W, or PLII thermocouple: (±1% of PV or ±10°C, whichever is greater) ±1 digit max.

Other thermocouple: (

±1% of PV or ±4°C, whichever is greater) ±1 digit max. *4

Input sampling period

50 ms

Hysteresis

Temperature input: 0.1 to 999.9

°C or °F (in units of 0.1°C or °F)

Analog input: 0.01% to 99.99% FS (in units of 0.01% FS)

Proportional band (P)

Temperature input: 0.1 to 999.9

°C or °F (in units of 0.1°C or °F)

Analog input: 0.1% to 999.9% FS (in units of 0.1% FS)

Integral time (I)

0 to 9999 s (in units of 1 s), 0.0 to 999.9 s (in units of 0.1 s)

Derivative time (D)

0 to 9999 s (in units of 1 s), 0.0 to 999.9 s (in units of 0.1 s)

Proportional band (P) for cooling

Temperature input: 0.1 to 999.9

°C or °F (in units of 0.1°C or °F)

Analog input: 0.1% to 999.9% FS (in units of 0.1% FS)

Integral time (I) for cooling

0 to 9999 s (in units of 1 s), 0.0 to 999.9 s (in units of 0.1 s)

Derivative time (D) for cooling

0 to 9999 s (in units of 1 s), 0.0 to 999.9 s (in units of 0.1 s)

Control period

0.1, 0.2, 0.5, 1 to 99 s (in units of 1 s)

Manual reset value

0.0% to 100.0% (in units of 0.1%)

Alarm setting range

−1,999 to 9,999 (decimal point position depends on input type)

Influence of signal source

resistance

Thermocouple: 0.1

°C/Ω max. (100 Ω max.), Platinum resistance thermometer: 0.1°C/Ω max. (10 Ω max.)

Insulation resistance

20 M

Ω min. (at 500 VDC)

Dielectric strength

3,000 VAC, 50/60 Hz for 1 min between terminals of different charge

Vibration

Malfunction

10 to 55 Hz, 20 m/s2 for 10 min each in X, Y and Z directions

Resistance

10 to 55 Hz, 20 m/s2 for 2 hr each in X, Y, and Z directions

Shock

Malfunction

100 m/s2, 3 times each in X, Y, and Z directions

Resistance

300 m/s2, 3 times each in X, Y, and Z directions

Weight

Main unit: Approx. 80 g, Models with Screw Terminal Unit: Approx. 40 g,

Models with Push-In Plus Terminal Unit: Approx. 40 g

Degree of protection

Main unit: IP20, Terminal unit: IP00

Memory protection

Non-volatile memory (number of writes: 1,000,000 times)

Setup Tool

CX-Thermo version 4.6 or higher

Setup Tool port

E5DC/E5DC-B bottom panel: An E58-CIFQ2 USB-Serial Conversion Cable is used to connect a USB port

on the computer.

E5DC/E5DC-B front panel: An E58-CIFQ2 USB-Serial Conversion Cable and E58-CIFQ2-E Conversion

Cable are used together to connect a USB port on the computer.

Standards

Approved standards

cULus: UL 61010-1/CSA C22.2 No.61010-1, Korean wireless regulations (Radio law: KC Mark) (Some

models only.)

*7, Lloyd's standards (E5DC only) *8, EAC

Conformed standards EN 61010-1 (IEC 61010-1), RCM

EMC

EMI:

EN61326-1

Radiated Interference Electromagnetic Field Strength: EN55011 Group 1, class A

Noise Terminal Voltage:

EN55011 Group 1, class A

EMS:

EN61326-1

ESD Immunity:

EN61000-4-2

Electromagnetic Field Immunity:

EN61000-4-3

Burst Noise Immunity:

EN61000-4-4

Conducted Disturbance Immunity:

EN61000-4-6

Surge Immunity:

EN61000-4-5

Voltage Dip/Interrupting Immunity:

EN61000-4-11
