E5CC/E5CC-B/E5CC-U

Specifications

Ratings

*1. There are no optional functions for the E5CC-U. Refer to Model Number Legend and List of Models on page 21.

*2. This function is not supported by the E5CC-B. Refer to Model Number Legend on page 20.

*3. With the E5CC-B, there can be up to four set points if event inputs are used to select them.

Power supply voltage

A in model number: 100 to 240 VAC, 50/60 Hz

D in model number: 24 VAC, 50/60 Hz; 24 VDC

Operating voltage range

85% to 110% of rated supply voltage

Power consumption

Models with option selection of 000:5.2 VA max. at 100 to 240 VAC, and 3.1 VA max. at 24 VAC or

1.6 W max. at 24 VDC

All other models: 6.5 VA max. at 100 to 240 VAC, and 4.1 VA max. at 24 VAC or 2.3 W max. at 24 VDC

Sensor input

Temperature input

Thermocouple: K, J, T, E, L, U, N, R, S, B, C/W, or PL II

Platinum resistance thermometer: Pt100 or JPt100

Infrared temperature sensor (ES1B): 10 to 70°C, 60 to 120°C, 115 to 165°C, or 140 to 260°C

Analog input

Current input: 4 to 20 mA or 0 to 20 mA

Voltage input: 1 to 5 V, 0 to 5 V, 0 to 10 V,or 0 to 50 mV (The 0 to 50 mV range applies to the

E5CC-U only for those manufactured in May 2014 or later.)

Input impedance

Current input: 150

Ω max., Voltage input: 1 MΩ min.

(Use a 1:1 connection when connecting the ES2-HB-N/THB-N.)

Control method

ON/OFF control or 2-PID control (with auto-tuning)

Control

output

Relay output

E5CC/E5CC-B: SPST-NO, 250 VAC, 3 A (resistive load), electrical life: 100,000 operations,

minimum applicable load: 5 V, 10 mA (reference value)

E5CC-U:

SPDT, 250 VAC, 3 A (resistive load), electrical life: 100,000 operations,

minimum applicable load: 5 V, 10 mA (reference value)

Voltage output

(for driving SSR)

Output voltage: 12 VDC

±20% (PNP), max. load current: 21 mA, with short-circuit protection circuit

Linear current output

4 to 20 mA DC/0 to 20 mA DC, load: 500

Ω max., resolution: approx. 10,000

Auxiliary

output

Number of outputs

E5CC: 3

E5CC-B: 2

E5CC-U: 1 or 2 (depends on model)

Output specifications

SPST-NO relay outputs, 250 VAC, Models with 1 output: 3 A (resistive load), E5CC-U models with 2

outputs: 3 A (resistive load), E5CC-B models with 2 outputs: 2 A (resistive load), Models with 3

outputs: 2 A (resistive load), Electrical life: 100,000 operations, Minimum applicable load: 10 mA at

5 V (reference value)

Event

input

Number of inputs

E5CC: 2 or 4 (depends on model)

E5CC-B: 2 (depends on model)

External contact input

specifications

Contact input: ON: 1 k

Ω max., OFF: 100 kΩ min.

Non-contact input: ON: Residual voltage: 1.5 V max., OFF: Leakage current: 0.1 mA max.

Current flow: Approx. 7 mA per contact

Transfer

output

Number of outputs

1 (only on models with a transfer output)

Output specifications

Current output: 4 to 20 mA DC, load: 500

Ω max., resolution: approx. 10,000

Linear voltage output: 1 to 5 VDC, load: 1 k

Ω min., resolution: Approx. 10,000

Setting method

Digital setting using front panel keys

Remote SP input

*1 *2

Current input: 4 to 20 mA DC or 0 to 20 mA DC (input impedance: 150

Ω max.)

Voltage input: 1 to 5 V, 0 to 5 V, or 0 to 10 V (input impedance: 1 M

Ω min.)

Indication method

11-segment digital display and individual indicators

Character height: PV: 15.2 mm, SV: 7.1 mm

Multi SP

Up to eight set points (SP0 to SP7) can be saved and selected using the event inputs, key operations,

or serial communications.

Bank switching

None

Other functions

Manual output, heating/cooling control, loop burnout alarm, SP ramp, other alarm functions, heater

burnout (HB) alarm (including SSR failure (HS) alarm), 40% AT, 100% AT, MV limiter, input digital

filter, self tuning, robust tuning, PV input shift, run/stop, protection functions, extraction of square root,

MV change rate limit, logic operations, temperature status display, simple programming, moving

average of input value, and display brightness setting

Ambient operating temperature

−10 to 55°C (with no condensation or icing), For 3-year warranty: −10 to 50°C with standard mounting

(with no condensation or icing)

Ambient operating humidity

25% to 85%

Storage temperature

-25 to 65°C (with no condensation or icing)

Altitude

2,000 m max.

Recommended fuse

T2A, 250 VAC, time-lag, low-breaking capacity

Installation environment

Overvoltage category II, Pollution Degree 2 (EN/IEC/UL 61010-1)
