E5GC

Model Number Legend and Standard Models

Model Number Legend

E5GC-

@@ @@@ M-@@@ (Example: E5GC-RX1A6M-015)

−− − − − − −−−

AB C D E

*1. The control output can be used as a simple transfer output.

*2. Only option 000 can be selected if an auxiliary output is zero.

*3. Option 016 and 023 can be selected only if two auxiliary outputs are selected.

*4. Option with HB and HS alarms (023) cannot be selected if a linear current output is selected for the control output.

*5. Option 024 can be selected only if one auxiliary output is selected.

*6. The specifications are different for Temperature Controllers with Push-In Plus terminal blocks. Refer to Precautions when Wiring on page 131.

Heating and Cooling Control

Using Heating and Cooling Control

Control Output Assignment

An auxiliary output is used as the cooling control output.

Control

If PID control is used, you can set PID control separately for heating and cooling.

This allows you to handle control systems with different heating and cooling response characteristics.

Model

Meaning

Control

outputs 1

and 2

No. of

auxiliary

outputs

Power

supply

voltage

Terminal

type

Input

type

Options

E5GC

× 24 mm

Control output 1

Control output 2

Relay output

None

Voltage output

(for driving SSR)

None

*1CX

Linear current output

None

*20

None

100 to 240 VAC

24 VAC/DC

Screw terminal blocks (with cover)

Screwless clamp terminal blocks

Universal input

HB alarm and HS alarm

Communications Event inputs

000

---

015

---

RS-485

---

016

---

*3, *4

023

---

024

---
