TTP Continuous polyester for decals

Catalog 1654227

Dimensions not italicized are

Dimensions are shown for

USA: 1-800-522-6752

South America: 55-11-3611-1514

Revised 04-07

in millimeters while dimensions

reference purposes only.

Canada: 1-905-470-4425

Hong Kong: 852-2735-1628

in inches are italicized.

Specifications subject

Mexico: 01-800-733-8926

Japan: 81-44-844-8013

www.tycoelectronics.com

to change.

C. America: 52-55-5-729-0425

UK: 44-141-810-8967

Performance Labels

The system is designed for applications that require a high-

durability label with all the features of a “silk-screened” label, only

without the cost, time and inflexibility involved in obtaining a

silk-screened product. The product utilizes high performance

polyester with permanent acrylic adhesive. It is thermal transfer

printable with all the capabilities of graphics, barcodes, logos and

several fonts. The product is available in several colors although

white, clear and metalized silver are available as standard. Typical

applications include panel labels, fascias, decalcomanias and asset

identification and rating plates. Typical industry use includes

aerospace, defense, electronics and infrastructure.

Features and benefits

I Efficient solution for expensive silk-screen printing

I Available in continuous format

I Several widths and colors available

I Interior and exterior aircraft use including flight

entertainment and deck instrumentation

I Thermal transfer printable

I Printable in any combination of material and ribbon colors

Temperature rating

Operating temperature range

Clear, White

-40°C to +150°C -40°F to +302°F

Metalized, and colors

Specifications/approvals

Tyco Electronics

TTDS- 031

Military

A-A-59485 (accelerated weather

resistance and salt spray)

Industry

GAT 100BB

UL 17292 Group PGJI2 (polywhite)

Printer information

Tyco Electronics printer

T312S (thermal transfer)

Tyco Electronics ribbon

1330-0607-10 (thermal transfer)

TTP 200 CL-10

Part numbering system

Length

Color

Label width (inches)

Product name
