iMC Laser or hand writable marking clip

Catalog 1654227

Dimensions not italicized are

Dimensions are shown for

USA: 1-800-522-6752

South America: 55-11-3611-1514

Revised 04-07

in millimeters while dimensions

reference purposes only.

Canada: 1-905-470-4425

Hong Kong: 852-2735-1628

in inches are italicized.

Specifications subject

Mexico: 01-800-733-8926

Japan: 81-44-844-8013

www.tycoelectronics.com

to change.

C. America: 52-55-5-729-0425

UK: 44-141-810-8967

Heat-Shrink/Cable Markers

Tyco Electronics iMC are marking clips designed for the identifica-

tion of wires and can be permanently attached to wires, post

termination.

They can be quickly and simply clipped on the wire or cable. The

polyester insert strip which can be printed using a laser printer or

written by hand is then inserted in the clip.

The marking clips are fastened without the need of cable ties.

Features and benefits

I Protects against damp, dust and dirt

I iMC polyester strip can be marked with a laser printer or

by hand

I Quick and flexible

I iMC strip is a dual color label with white on one side and

yellow on the other

Temperature rating

Operating temperature

0° to +80°C

(+32° to +176°F)

Printer Information

Standard laser printer with auto/manual sheet feed

Contact Tyco Electronics Electronics Identification for more information.
