NMX Flame retardant, light weight tie-on cable marker tags

Catalog 1654227

Dimensions not italicized are

Dimensions are shown for

USA: 1-800-522-6752

South America: 55-11-3611-1514

Revised 04-07

in millimeters while dimensions

reference purposes only.

Canada: 1-905-470-4425

Hong Kong: 852-2735-1628

in inches are italicized.

Specifications subject

Mexico: 01-800-733-8926

Japan: 81-44-844-8013

www.tycoelectronics.com

to change.

C. America: 52-55-5-729-0425

UK: 44-141-810-8967

Heat-Shrink/Cable Markers

NMX 25625 WE 2.5

Part numbering system

Pack size

Color

Product size

Product family

NMX cable marker tags are used for identification of cables and

wire bundles by computer-based printing onto markers. The

markers are attached using cable ties. They are ideal for aerospace

and other cases where resistance to harsh environments and light

weight are important.

Features and benefits

I Extremely light weight

I Ultimate tensile strength and tear resistance

I Flame retardant

I Resistant to several avionics fluids, solvents and cleaners

I Dot matrix printable

I Available in white and yellow printable areas

Temperature rating

Operating temperature range

–40°C to +135°C

–40°F to +275°F

Specifications/approvals

Tyco Electronics

TTDS-030

Military

SAE AS81531 4.6.2,

MIL-STD-202 Method 215J

Industry

DMS 2325, DMS 2409

Printer information

Tyco Electronics printer

AM6310 (dot matrix)

Tyco Electronics ribbon

1892 BK01 (dot matrix)
