CMD Cable and wire marker dispenser

Catalog 1654227

Dimensions not italicized are

Dimensions are shown for

USA: 1-800-522-6752

South America: 55-11-3611-1514

Revised 04-07

in millimeters while dimensions

reference purposes only.

Canada: 1-905-470-4425

Hong Kong: 852-2735-1628

in inches are italicized.

Specifications subject

Mexico: 01-800-733-8926

Japan: 81-44-844-8013

www.tycoelectronics.com

to change.

C. America: 52-55-5-729-0425

UK: 44-141-810-8967

Self-Laminating Labels

Tyco Electronics CMD is one of the most user friendly portable

wire marker systems available. Each dispenser contains 10 rolls of

individually numbered marker tape. Each roll of markers contains

76 individual markers which are a convenient length that accom-

modates most commonly identified wire sizes.

Manufactured from DuPont Tyvek® material to ensure durability

and minimize the potential of tearing.

Features and benefits

■

Supplied with a pre-determined length of 32mm and a width of

6.4mm

■

Supplied in a handy pocket size reusable dispenser

■

Aggressive acrylic adhesive impervious to oil and water

Temperature rating

Operating temperature range

–40°C to +80°C

–40°F to +176°F

Specifications/approvals

Tyco Electronics

TTDS-141

CMD - 0-9

Part numbering system

Contents

Product family
