CC1150

SWRS037B – JANUARY 2006 – REVISED MARCH 2015

www.ti.com

Device and Documentation Support

7.1

Device Support

7.1.1

Device Nomenclature

To designate the stages in the product development cycle, TI assigns prefixes to the part numbers. Each

device has one of three prefixes: X, P, or null (no prefix) (for example, CC1150 is in production; therefore,

no prefix is assigned).

Device development evolutionary flow:

Experimental device that is not necessarily representative of the final device's electrical

specifications and may not use production assembly flow.

Prototype device that is not necessarily the final silicon die and may not necessarily meet

final electrical specifications.

null

Production version of the silicon die that is fully qualified.

Production devices have been characterized fully, and the quality and reliability of the device have been

demonstrated fully. TI's standard warranty applies.

Predictions show that prototype devices (X or P) have a greater failure rate than the standard production

devices. Texas Instruments recommends that these devices not be used in any production system

because their expected end-use failure rate still is undefined. Only qualified production devices are to be

used.

TI device nomenclature also includes a suffix with the device family name. This suffix indicates the

package type (for example, RGV).

For orderable part numbers of CC1150 devices in the RGV

package types, see the Package Option Addendum of this document, the TI website (www.ti.com), or

contact your TI sales representative.

7.2

Documentation Support

The following documents describe the CC1150 device. Copies of these documents are available on the

Internet at www.ti.com.

1. [1] CC1150EM 315 – 433 MHz Reference Design (SWRR041)

2. [2] CC1150EM 868 – 915 MHz Reference Design (SWRR042)

3. [3] DN012 Programming Output Power on CC1100 and CC1150 (SWRA150)

4. [5] DN006 CC11xx Settings for FCC 15.247 Solutions (SWRA123)

5. [6] DN017 CC11xx 868/915 MHz Matching (SWRA168)

6. [7] AN058 Antenna Selection Guide (SWRA161)

7. [8] CC1150 Errata Notes (SWRZ018)

8. [9] DN501 PATABLE Access (SWRA110)

9. [10] AN001 SRD Regulations for Licence Free Transceiver Operation (SWRA090)

10. [11] (SmartRF Studio)

11. [12] CC1100/CC1150DK and CC2500/CC2550DK Development Kit Examples and Libraries User

Manual (SWRU109)

7.2.1

Community Resources

The following links connect to TI community resources. Linked contents are provided "AS IS" by the

respective contributors. They do not constitute TI specifications and do not necessarily reflect TI's views;

see TI's Terms of Use.

Device and Documentation Support

Submit Documentation Feedback

Product Folder Links: CC1150
