Mitsubishi microcomputers

M16C / 62A Group

SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER

Timer

There are eleven 16-bit timers. These timers can be classified by function into timers A (five) and timers B

(six). All these timers function independently. Figures 1.14.1 and 1.14.2 show the block diagram of timers.

• Timer mode

• One-shot mode

• PWM mode

• Timer mode

• One-shot mode

• PWM mode

• Timer mode

• One-shot mode

• PWM mode

• Timer mode

• One-shot mode

• PWM mode

• Timer mode

• One-shot mode

• PWM mode

• Event counter mode

TA0IN

TA1IN

TA2IN

TA3IN

TA4IN

Timer A0

Timer A1

Timer A2

Timer A3

Timer A4

f1 f8 f32 fC32

Timer A0 interrupt

Timer A1 interrupt

Timer A2 interrupt

Timer A3 interrupt

Timer A4 interrupt

Noise

filter

Noise

filter

Noise

filter

Noise

filter

Noise

filter

1/32

fC32

1/8

1/4

f32

XIN

XCIN

Clock prescaler reset flag (bit 7

at address 038116) set to “1”

Reset

Clock prescaler

Timer B2 overflow

Note 1: The TA0IN pin (P71) is shared with RxD2 and the TB5IN pin, so be careful.

Figure 1.14.1. Timer A block diagram
