 3 / 9 page
background image
UT4450
Power MOSFET
UNISONICTECHNOLOGIESCO.,LTD
3 of 9
www.unisonic.com.tw
QW-R502-898, C
ABSOLUTE MAXIMUM RATINGS (TA=25°C, unless otherwise noted)
PARAMETER
SYMBOL
RATINGS
UNIT
Drain-Source Voltage
VDSS
40
V
Gate-Source Voltage
VGSS
±20
V
Drain Current
Continuous
TA=25°C
ID
7
A
TA=70°C
5.5
A
Pulsed (Note 1)
IDM
45
A
Avalanche Current (Note 1)
IAS
14
A
Avalanche Energy
L=0.1mH (Note 1)
EAS
10
mJ
Power Dissipation (Note 2)
TA=25°C
PD
3.1
W
TA=70°C
2
W
Junction Temperature
TJ
-55~+150
°C
Storage Temperature Range
TSTG
-55~+150
°C
Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
THERMAL CHARACTERISTICS
PARAMETER
SYMBOL
MIN
TYP
MAX
UNIT
Junction to Ambient
t ≤10s (Note 3)
θJA
31
40
°C/W
Steady-State (Note 3, 4)
59
75
°C/W
Notes: 1. Repetitive rating, pulse width limited by junction temperature TJ(MAX)=150°C. Ratings are based on low
frequency and duty cycles to keep initialTJ=25°C.
2. Based on TJ(MAX)=150°C, using≤10s.
3. The device is measured that mounted on 1in
2 FR-4 board with 2oz. Copper, in a still air environment with
TA=25°C. The value in any given application depends on the user's specific board design.
4. The θJA is the sum of the thermal impedence from junction to lead θJL and lead to ambient.
