23 / 42 page ![]() www.ams.com Revision 1.0 23 - 42 AS3953 Datasheet - A pp l ic a t io n I n f or m a t i on Figure 6. Signal to Controller 8.1.1 Writing of Data to Addressable Registers (Register Write Mode) Following figures show cases of writing a single byte and writing multiple bytes with auto-incrementing address. After the SPI operation mode bits, the address of register to be written is provided. Then one or more data bytes are transferred from the SPI, always from the MSB to the LSB. The data byte is written in register on falling edge of its last clock. In case the communication is terminated by putting /SS high before a packet of 8 bits composing one byte is sent, writing of this register is not performed. In case the register on the defined address does not exist or it is a read only register no write is performed. Note: When the AS3953 is powered via vp_SPI and not via field; the registers and EEPROM can be readout. When CS is set to low, after 50us of the falling edge, the Registers and the EEPROM can be readout. Nevertheless, if there is no activity for 1ms, there is a timeout and the logic goes to sleep, hence losing the values in the registers. (EEPROM values are retained). Figure 7. Writing of a Single Register Figure 8. Writing of Register Data with Auto-incrementing Address MOSI MISO MISO MOSI AS3953 MOSI MISO I/O AS3953 µC µC Separate SPI Input and Output Signals to Controller Bi-directional Data IO Signal to Controller 0 0 0 A4 A3 A2 A1 A0 D5 D4 D3 D2 D1 D0 D7 D6 X X SCLK rising edge Data is transfered from µC SCLK falling edge Data is sampled Data is moved to Address A4-A0 /SS rising edge signals end of WRITE Mode Three leading bits indicate Mode /SS SCLK MOSI 00 0 A 4 A 3 A 2 A 1 A 0 D 5 D 4 D 3 D 2 D 1 D 0 D 7 D 6 X X Data is moved to Address <A4-A0> + n /SS raising edge signals end of WRITE Mode Three leading bits indicate Mode D 5 D 4 D 3 D 2 D 1 D 0 D 7 D 6 D 7 D 6 D 5 D 4 D 3 D 2 D 1 D 0 D 7 D 6 D 1 D 0 Data is moved to Address <A4-A0> + (n-1) Data is moved to Address <A4-A0> + 1 Data is moved to Address <A4-A0> /SS SCLK MOSI |
|
