U74LVC86A

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

4 of 6

www.unisonic.com.tw

QW-R502-783.A

ELECTRICAL CHARACTERISTICS

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

IOH = -100μA, VCC = 1.65V ~ 3.6V

VI = VIH or VIL

VCC - 0.2

IOH = -4mA, VCC = 1.65V

VI = VIH or VIL

1.29

IOH = -8mA, VCC = 2.3V

VI = VIH or VIL

1.9

IOH = -12mA, VCC = 2.7V

VI = VIH or VIL

2.2

VCC

IOH = -18mA, VCC = 3.0V

VI = VIH or VIL

2.4

High-Level Output Voltage

VOH

IOH = -24mA, VCC = 3.0V

VI = VIH or VIL

2.3

IOH = 100μA, VCC = 1.65V ~ 3.6V

VI = VIH or VIL

0.1

IOH = 4mA, VCC = 1.65V,

VI = VIH or VIL

0.24

IOH = 8mA, VCC = 2.3V,

VI = VIH or VIL

0.3

IOH = 12mA, VCC = 2.7V,

VI = VIH or VIL

0.4

Low-Level Output Voltage

VOL

IOH = 24mA, VCC = 3.0V,

VI = VIH or VIL

0.55

Input Leakage Current

II(LEAK)

VIN = 5.5V or GND,

VCC = 3.6V

±0.1

±1

μA

Quiescent Supply Current

ICC

VIN = VCC or GND, IOUT = 0,

VCC = 3.6V

0.1

μA

Additional quiescent Supply

Current

Δ ICC

One input at VCC – 0.6V,

other inputs at VCC or GND,

IOUT = 0, VCC = 2.7V ~ 3.6V

500

μA

Input Capacitance

CIN

VIN = VCC or GND, VCC=3.3V

5.0

Note: 1. All typical values are at VCC = 3.3 V, TA = 25 °C

SWITCHING CHARACTERISTICS

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP MAX UNIT

VCC = 1.2V, CL = 50 pF, RL = 500Ω

VCC = 1.8V ±0.15V, CL = 30 pF, RL = 1KΩ

4.1

9.4

VCC = 2.5V ±0.2V, CL = 50 pF, RL = 500Ω

2.9

7.1

VCC = 2.7V, CL = 50 pF, RL= 500Ω

2.8

5.4

Propagation delay from input

(A or B) to output (Y)

tPLH/tPHL

VCC = 3.3 ±0.3V, CL = 30pF, RL= 500Ω

2.5

4.4

Note: 1. All typical values are at VCC = 3.3 V, TA = 25 °C

OPERATING CHARACTERISTICS

PARAMETER

SYMBOL

TEST CONDITIONS

TYP

UNIT

Power Dissipation Capacitance Per Gate

Cpd

VCC = 3.3V
