background image
U74LVC86A
CMOS IC
UNISONICTECHNOLOGIESCO.,LTD
3 of 6
www.unisonic.com.tw
QW-R502-783.A
ABSOLUTE MAXIMUM RATING (TA =25°C , unless otherwise specified)
PARAMETER
SYMBOL
TEST CONDITIONS
UNIT
Supply Voltage
VCC
-0.5 ~ 6.5
V
Input Voltage
VIN
-0.5 ~ 5.5
V
Output Voltage (any output in the high or low state)
VOUT
-0.5 ~ +VCC+0.5
V
Input Clamp Current
IIK
-50
mA
Output Clamp Current
IOK
-50
mA
Output Current
IOUT
±50
mA
VCC or GND Current
ICC
±100
mA
Power Dissipation
TA=-40°C to +125°C
PD
500
mW
Storage Temperature
TSTG
-65 ~ +150
°C
Notes: 1. The input and output voltage ratings may be exceeded if the input and output current ratings are observed.
2. Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
THERMAL DATA
PARAMETER
SYMBOL
RATING
UNIT
Junction to Ambient
θJA
115
°C/W
RECOMMENDED OPERATING CONDITIONS
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
MAX
UNIT
Max. speed performance
2.7
3.6
Supply Voltage
VCC
Low-voltage applications
1.2
3.6
V
VCC = 1.2V
VCC
VCC = 1.65V ~ 1.95V
0.65 × VCC
VCC = 2.3V ~ 2.7V
1.7
High-Level Input Voltage
VIH
VCC = 2.7V ~ 3.6V
2.0
V
VCC = 1.2V
GND
VCC = 1.65V ~ 1.95V
0.35 × VCC
VCC = 2.3V ~ 2.7V
0.7
Low-Level Input Voltage
VIL
VCC = 2.7V ~ 3.6V
0.8
V
Input Voltage
VIN
0
5.5
V
Output Voltage
VOUT
0
VCC
V
VCC=1.2 ~ 2.7V
20
Input Transition Rise or Fall Rate
Δt/Δv
VCC=2.7 ~ 3.6V
10
ns/V
Operating Temperature
TA
-40
+85
°C
