ADP1046ACPZ-R7 datasheet(79/96 Pages) AD

79 / 96 page

Data Sheet

ADP1046

Rev. 0 | Page 79 of 96

Table 110. Register 0x6E—Dead Time 6

Bits

Bit Name

R/W

Description

t11 polarity

R/W

0 = positive polarity; 1 = negative polarity.

[6:4]

t11 offset

R/W

This value multiplied by Register 0x70[2:0] determines the t11 offset from nominal timing at no load.

Bit 6

Bit 5

Bit 4

Offset (ns)

t12 polarity

R/W

0 = positive polarity; 1 = negative polarity.

[2:0]

t12 offset

R/W

This value multiplied by Register 0x70[2:0] determines the t12 offset from nominal timing at no load.

Bit 2

Bit 1

Bit 0

Offset (ns)

Table 111. Register 0x6F—Dead Time 7

Bits

Bit Name

R/W

Description

t13 polarity

R/W

0 = positive polarity; 1 = negative polarity.

[6:4]

t13 offset

R/W

This value multiplied by Register 0x70[2:0] determines the t13 offset from nominal timing at no load.

Bit 6

Bit 5

Bit 4

Offset (ns)

t14 polarity

R/W

0 = positive polarity; 1 = negative polarity.

[2:0]

t14 offset

R/W

This value multiplied by Register 0x70[2:0] determines the t14 offset from nominal timing at no load.

Bit 2

Bit 1

Bit 0

Offset (ns)
