Table 78. Register 0x4E—OUTD Rising Edge Setting (OUTD Pin)

Bits

Bit Name

R/W

Description

[7:4]

R/W

These bits contain the four LSBs of the 12-bit t7 time. This value is always used with the eight

bits of Register 0x4D, which contains the eight MSBs of the t7 time. Each LSB corresponds to

5 ns resolution. The entire switching period is divided into 40 ns time steps. If the t_rise and

t_fall of a PWM edge occur within the same 40 ns time step, the PWM output is 0 V. If the t_rise

and t_fall occur in different 40 ns time steps, the PWM output is set to the programmed value.

The absolute maximum pulse width is tPERIOD − 5 ns.

Modulate enable

R/W

1 = PWM modulation acts on the t7 edge.

0 = no PWM modulation of the t7 edge.

t7 sign

R/W

1 = negative sign. Increase of PWM modulation moves t7 right.

0 = positive sign. Increase of PWM modulation moves t7 left.

Reserved

R/W

Reserved.

Volt-second balance

source selection

R/W

If this bit is set to 1, the OUTD rising edge is selected as the start of the integration period for

volt-second balance.

Table 79. Register 0x4F—OUTD Falling Edge Timing (OUTD Pin)

Bits

Bit Name

R/W

Description

[7:0]

R/W

This register contains the eight MSBs of the 12-bit t8 time. This value is always used with the top

four bits of Register 0x50, which contains the four LSBs of the t8 time. Each LSB corresponds to

5 ns resolution. The entire switching period is divided into 40 ns time steps. If the t_rise and

t_fall of a PWM edge occur within the same 40 ns time step, the PWM output is 0 V. If the t_rise

and t_fall occur in different 40 ns time steps, the PWM output is set to the programmed value.

The absolute maximum pulse width is tPERIOD − 5 ns.

Table 80. Register 0x50—OUTD Falling Edge Setting (OUTD Pin)

Bits

Bit Name

R/W

Description

[7:4]

R/W

These bits contain the four LSBs of the 12-bit t8 time. This value is always used with the eight

bits of Register 0x4F, which contains the eight MSBs of the t8 time. Each LSB corresponds to

5 ns resolution. The entire switching period is divided into 40 ns time steps. If the t_rise and

t_fall of a PWM edge occur within the same 40 ns time step, the PWM output is 0 V. If the t_rise

and t_fall occur in different 40 ns time steps, the PWM output is set to the programmed value.

The absolute maximum pulse width is tPERIOD − 5 ns.

Modulate enable

R/W

1 = PWM modulation acts on the t8 edge.

0 = no PWM modulation of the t8 edge.

t8 sign

R/W

1 = negative sign. Increase of PWM modulation moves t8 right.

0 = positive sign. Increase of PWM modulation moves t8 left.

[1:0]

Reserved

R/W

Reserved.

Table 81. Register 0x51—SR1 Rising Edge Timing (SR1 Pin)

Bits

Bit Name

R/W

Description

[7:0]

R/W

This register contains the eight MSBs of the 12-bit t9 time. This value is always used with the top

four bits of Register 0x52, which contains the four LSBs of the t9 time. Each LSB corresponds to

5 ns resolution. The entire switching period is divided into 40 ns time steps. If the t_rise and

t_fall of a PWM edge occur within the same 40 ns time step, the PWM output is 0 V. If the t_rise

and t_fall occur in different 40 ns time steps, the PWM output is set to the programmed value.

The absolute maximum pulse width is tPERIOD − 5 ns. It is recommended that the SR1 rising edge

not be set between 80 ns and 115 ns when using the SR soft start.
