UTT4407L-S08-R datasheet(4/4 Pages) UTC

4 / 4 page

UTT4407

Preliminary

Power MOSFET

UNISONICTECHNOLOGIESCO.,LTD

4 of 4

www.unisonic.com.tw

QW-R502-554.a

ELECTRICAL CHARACTERISTICS (TJ =25°C, unless otherwise noted)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX UNIT

OFF CHARACTERISTICS

Drain-Source Breakdown Voltage

BVDSS VGS =0 V, ID =-250µA

-30

VDS =-24V,VGS =0 V

-1

Drain-Source Leakage Current

IDSS

VDS =-24V,VGS =0 V,TJ =55°C

-5

µA

Forward

VGS=+25V,VDS=0V

+100

Gate- Source Leakage Current

Reverse

IGSS

VGS=-25V,VDS=0V

-100

µA

ON CHARACTERISTICS

Gate Threshold Voltage

VGS(TH) VDS =VGS, ID =-250 µA

-1.7

-2.5

-3

VGS =-10V, ID =-10A

mΩ

VGS=-10V,ID =-10A,TJ =125°C

mΩ

VGS =-20V, ID =-10A

mΩ

Drain-Source On-State Resistance

RDS(ON)

VGS =-4.5V, ID =-10A

mΩ

DYNAMIC PARAMETERS

Input Capacitance

CISS

2076 2500

Output Capacitance

COSS

503

Reverse Transfer Capacitance

CRSS

VDS =-15 V, VGS =0V, f=1MHz

302

Gate Resistance

VDS =0V, VGS =0V, f=1MHz

Ω

SWITCHING PARAMETERS

Total Gate Charge

37.2

Gate Source Charge

QGS

Gate Drain Charge

QGD

VDS =-15V,VGS =-10V,

ID=-12A

10.4

Turn-ON Delay Time

tD(ON)

12.4

Turn-ON Rise Time

8.2

Turn-OFF Delay Time

tD(OFF)

25.6

Turn-OFF Fall-Time

VDS =-15V, VGS =-10V,

RL=1.25Ω, RGEN=3Ω

SOURCE-DRAIN DIODE RATINGS AND CHARACTERISTICS

Drain-Source Diode Forward Voltage

VSD

IS=-1A, VGS=0V

-0.72

-1

Maximum Continuous Drain-Source Diode

Forward Current

-4.2

Body Diode Reverse Recovery Time

tRR

IF=-12 A, dI/dt=100A/μs

Body Diode Reverse Recovery Charge

QRR

IF=-12A, dI/dt=100A/μs

UTC assumes no responsibility for equipment failures that result from using products at values that

exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or

other parameters) listed in products specifications of any and all UTC products described or contained

herein. UTC products are not designed for use in life support appliances, devices or systems where

malfunction of these products can be reasonably expected to result in personal injury. Reproduction in

whole or in part is prohibited without the prior written consent of the copyright owner. The information

presented in this document does not form part of any quotation or contract, is believed to be accurate

and reliable and may be changed without notice.
