 2 / 5 page
background image
INCHANGE Semiconductor
isc RF Product Specification
isc Silicon NPN RF Transistor
2SC3545
ELECTRICAL CHARACTERISTICS
TC=25℃ unless otherwise specified
SYMBOL
PARAMETER
CONDITIONS
MIN
TYP.
MAX
UNIT
VCE(sat)
Collector-Emitter Saturation Voltage
IC= 10mA ; IB= 1mA
0.5
V
ICBO
Collector Cutoff Current
VCB= 12V; IE= 0
0.1
μA
hFE
DC Current Gain
IC= 5mA ; VCE= 10V
50
250
fT
Current-Gain—Bandwidth Product
IE= -5mA ; VCE= 10V
1.3
2.0
GHz
Cre
Feedback Capacitance
IE= 0 ; VCB= 10V;f= 1.0MHz
0.48
1.0
pF
rbb’ • CC
Base Time Constant
VCE= 10V,IE = -5mA,f = 31.9 MHz
4
10
ps
hFE Classifications
Class
M/P
L/Q
K/R
Marking
T42
T43
T44
hFE
50-100
70-140
120-250
isc Website：www.iscsemi.cn
