34 / 48 page ![]() DDR2 SDRAM controller interface description STLS2F01 34/48 operation returns. In general, It is equal to or less than half period of ACALAT_LIN. The Value of CASLAT_LIN is twice of the one of CAS. 5. CONF_CTL_15 DLL_INCREMENT The parameter should not be set 0. 6. CONF_CTL_15 DLL_START_POINT The parameter should not be set 0/1 and should be less than the 1.5 times of DLL_LOCK_VALUE. 7. CONF_CTL_28 UB_DIMM The parameter should be set 1, when unbuffered DIMM(s) are used. It should be set 0, when the SDRAM(s) are used. 4.5 DDR2 SDRAM sample mode configuration DDR2 SDRAM controller is integrated in the STLS2F01. And the delay compensation circuit (using DLL) is used to sample return data of DQS. Since there is the delay of data return path between the memory controller and SDRAM module, it is necessary to introduce a set of control signals used to measure the delay. The control signals of DDR2_GATE_I[3:0] and DDR2_GATE_O[3:0] are used to the delay measurement. On the PCB, DDR2_GATE_I and DDR2_GAT_O are connected together to imitate the wiring delay on the PCB. Thus, the accuracy of sampling can be guaranteed. |
|
