E3X-NH

Attachments

E39-F1

Long-distance Lens Unit

E39-F3

Lens-equipped Reflective Unit

Note:

One set includes two units.

E39-F2

Side-view Unit

E39-F5

Side-view Reflective Unit

E39-F3A

Small Spot Lens Unit

4 dia.

M2.6

Effective depth: 3.2

Spot facing depth: 0.9

2.8 dia.

M2 x 2

4 dia.

6 dia.

Lens (3.7 dia.)

2.1 dia.

Note:

When mounting, remove all of the accompanying

screws first and then screw the E32-TC200A into

the E39-F5 until the stopper comes into contact.

Note:

One set includes two units.

4 dia.

M2.6 x 0.45

Effective depth: 3.8

Spot facing depth: 0.9

Sensing hole

Two, 3.2 dia.

Two, M3

Fiber Unit mounting

holes (E32-TC200A)

Two, 3.2 dia.

Mounting hole

Two, 4 dia.

M3 toothed

washers

Two,

3.2 dia.

M3 x 6 Angle

fixing screw

Two, M3 x 3 Slotted

head machine screw

E39-F1

Lens

Unit

Installation

Connection

Connection with S3D2 Sensor Controller

Note:

A maximum of two E3X-NH Sensors can be connected.

+12 V

0 V

Blue

Black

Brown

IN1

Power supply voltage

Output

Functions

Model

100 to 240 VAC

Relay

AND, OR

S3D2-AK

AND, OR, and timer

S3D2-CK

Flip-flop

S3D2-BK

Transistor

AND, OR, and timer

S3D2-CC

Relay

2 inputs, 2 outputs,

S3D2-DK

2 inputs, 2 outputs, and timer

S3D2-EK

24 VDC

AND, OR

S3D2-AKD

AND, OR, and timer

S3D2-CKD
