E3X-NH

E3X-NH

2

Fiber Units

Through-beam/Slot Sensors

Indicates models that allow free cutting. Models without this mark do not allow free cutting.

: E3X-NH

j

: E3X-NHB

j

Application

Features

Appearance

Sensing distance (mm) *

(Values in parentheses: when

using the E39-F1 Lens Unit)

Standard object

(min. sensing

object: opaque)

Model

Permis-

sible

bending

radius

Long distance

M4

M4 screw

(2,000)

90 (250)

700

1.4-mm dia.

(0.06-mm dia.)

E32-T11L

25 mm

3 dia.

3-mm dia.

700

90

E32-T12L

M3

M3 screw

200

0.9-mm dia.

(0.04-mm dia.)

E32-T21L

2 dia.; small diameter

2-mm dia.

200

E32-T22L

M14; with lens; ideal

for explosion-proof

applications

M4 screw

14,000

2,000

10-mm dia.

(0.2-mm dia.)

E32-T17L

General-pur-

pose

M4

M4 screw

(3,000)

55 (420)

400

1.0-mm dia.

(0.04-mm dia.)

E32-TC200

25 mm

M3; possible to

mount the reflective

side-view conversion

attachment E39-F5

M3 screw

360

55

E32-TC200A

M3; for detecting

minute sensing

objects

M3 screw

100

0.5-mm dia.

(0.04-mm dia.)

E32-TC200E

Thin fiber

2 dia.; for detecting

minute sensing

objects

2-mm dia.

100

0.5-mm dia.

(0.04-mm dia.)

E32-T22

25 mm

1.2 dia.; with sleeve

M4 screw

90 mm (40 mm)

( ): E32-TC200B4

1.2 dia.

400

55

1.0-mm dia.

(0.04-mm dia.)

E32-TC200B

E32-TC200B4

0.9 dia.; with sleeve

M3 screw

90 mm (40 mm)

( ): E32-TC200F4

0.9 dia.

100

0.5-mm dia.

(0.04-mm dia.)

E32-TC200F

E32-TC200F4

Flexible (resists

breaking) (R1)

Possible to bend like

electric wires (R1);

M4 screw

280

(2,100)

1-mm dia.

(0.1-mm dia.)

E32-T11R

1 mm

M3 screw

60

0.5-mm dia.

(0.1-mm dia.)

E32-T21R

Flexible (resists

breaking) (R4);

Ideal for mounting

on moving sections

(R4)

M4 screw

360

50

1.0-mm dia.

(0.04-mm dia.)

E32-T11

4 mm

M3 screw

100

0.5-mm dia.

(0.04-mm dia.)

E32-T21

Side-view

Long distance;

space-saving

3-mm dia.

240

30

1.0-mm dia.

(0.08-mm dia.)

E32-T14L

25 mm

Suitable for

detecting minute

sensing objects

1-mm dia.

90

0.5-mm dia.

(0.04-mm dia.)

E32-T24

Screw-mounting type

1,800

200

4.0-mm dia.

(0.08-mm dia.)

E32-T14

Note:

1. For common specifications of the Fiber Unit, refer to page 6.

2. The size of standard sensing object is the same as the fiber core diameter (lens diameter for models with lens).

3. The sensing distance of the minimum sensing object indicates the rated sensing distance unless otherwise specified.

4. Curled-cord models are also available for through-beam and reflective models.

*

Sensing distance indicates values for white paper.
