5-2.Electronic Characteristics

Parameter

Minimum

Typical

Maximum

Unit

Centre Frequency

--

947.500

--

MHz

3dB Bandwidth

--

±21

--

MHz

Usable Bandwidth

--

±15

--

MHz

Insertion Loss

IL

932.50 MHz …. 962.50 MHz

--

2.7

3.6

dB

Amplitude Variation (p-p)

Δ α

932.50 MHz …. 962.50 MHz

--

1.0

1.8

dB

Absolute Attenuation

α

DC …. 885.00 MHz

885.00 MHz …. 915.00 MHz

990.00 MHz …. 1050.0 MHz

1050.0 MHz …. 2000.0 MHz

45

18

20

48

54

25

28

58

--

--

--

--

dB

Input / Output Impedance

50

Ω

1.

2.

Unless noted otherwise, all measurements are made with the filter installed in the specified test fixture that is

connected to a 50

Ω test system with VSWR≤1.2:1. The test fixture L and C are adjusted for minimum insertion

the impedance matching component values and quality.

3.

Unless noted otherwise, specifications apply over the entire specified operating temperature range.

4.

The specifications of this device are based on the test circuit shown above and subject to change or

obsolescence without notice.

5.

All equipment designs utilizing this product must be approved by the appropriate government agency prior to

manufacture or sale.

6.

Our liability is only assumed for the Surface Acoustic Wave (SAW) component(s) per se, not for applications,

processes and circuits implemented within components or assemblies.
