LCDP1521
5/8
Pulse (µs)
Vp
C1
C2
LR1
R2
R3
R4
IPP
Rs
tr
tp
(V)
(
µF)
(nF)
(
µH)
(
Ω)(Ω)(Ω)(Ω)
(A)
(
Ω)
10
700
1500
20
200
0
50
15
25
25
10
110
1.2
50
1500
1
33
0
76
13
25
25
15
60
2
10
2500
10
0
1.1
1.3
0
3
3
10
245
This is a GO-NO GO test which allows to confirm the holding current (IH) level in a functional test circuit.
TEST PROCEDURE :
- Adjust the current level at the IH value by short circuiting the D.U.T.
- Fire the D.U.T. with a surge current : IPP = 10A, 10/1000
µs.
- The D.U.T. will come back to the off-state within a duration of 50ms max.
R
V
BAT = - 100V
Surge generator
D.U.T
FUNCTIONAL HOLDING CURRENT (IH) TEST CIRCUIT : GO-NO GO TEST
C2
R4
R3
TIP
RING
GND
VP
R2
R1
L
C1
(V is defined in unload condition)
P
TEST CIRCUIT FOR VFP AND VDGL PARAMETERS
