MPC5553 Microcontroller Data Sheet, Rev. 2.0

Mechanicals

Freescale Semiconductor

Mechanicals

4.1

Pinouts

4.1.1

MPC5553 416 PBGA Pinout

Figure 34, Figure 35, and Figure 36 show the pinout for the MPC5553 416 PBGA package. While the

MPC5553 and the MPC5554/MPC5565/MPC5566 are pin-compatible, the MPC5553 BGA is shown to

highlight the balls that are not connected to any signal on the MPC5553 (the eTPUB[0:31] and TSIZ[0:1]).

The alternate Fast Ethernet Controller (FEC) signals that are multiplexed with the data bus are not shown

for the MPC5553.

NOTE

Some pins have names that include functions that are not available on all

MPC55xx devices. For example, ball R25 of the 416 BGA package is named

‘SINA,’ but the MPC5553 does not have a DSPI A module. In this case, the

SINA pin can only be used for its alternate functions of GPIO[94] or

PCSC[2]. Refer to the specific device Reference Manual for functions

available on each device.
