Coil former

Material:

GFR polyterephthalate (UL 94 V-0, insulation class to IEC 60085:

F

max. operating temperature 155

°C), color code black

Solderability: to IEC 60068-2-20, test Ta, method 1 (aging 3): 235

°C, 2 s

Resistance to soldering heat: to IEC 60068-2-20, test Tb, method 1B: 350

°C, 3,5 s

Winding:

see “Processing Notes”, page 154

Also available without solder pins

Sections

mm

µΩ

Solder

pins

Ordering code

1

154

96,8

21,6

14

B65647-B1014-T1

1

154

96,8

21,6

—

B65647-A1000-T1

FPM0019-1

2,54

14

8

45,72

1

7

ø1,6+0,15

65,5 max.

20,2+0,2

ø23,4 max.

1,2 x 0,6

Marking of solder pin 1

Hole arrangement view

in mounting direction

ø3,5+0,2

Hole arrangement

View in mounting direction

B65647

Accessories

PM 50/39
