Coil former, squared pins

Material:

GFR thermosetting plastic (UL 94 V-0, insulation class to IEC 60085:

H

max. operating temperature 180

°C), color code black

Solderability: to IEC 60068-2-20, test Ta, method 1 (aging 3): 235

°C, 2 s

Resistance to soldering heat: to IEC 60068-2-20, test Tb, method 1B: 350

°C, 3,5 s

Winding:

see “Processing Notes”, page 153

For matching clamp and insulating washers see page 230

Sections

mm

µΩ

Pins

Ordering code

1

30

42

47

5

B65812-N1005-D1

8

B65812-N1008-D1

8

B65812-W1008-D1

12

B65812-N1012-D1

2

28,4

42

50

5

B65812-N1005-D2

8

B65812-N1008-D2

FRM0301-M

0,5

ø1+0,1

9

4

10

3

12

11

2

1

5

6

8

7

Erdungspunkte

ø1,3+0,1

0,2

_

ø9,95 0,15

10

_

Hole arrangement

View in mounting direction

Version

Pins omitted

5 pins

8 pins

3, 4, 6, 7, 9, 10, 12

3, 4, 9, 10

Ground

Ø 1,3 + 0,1

12 pins

B65812

Accessories

RM 8
