ABSOLUTE MAXIMUM RATINGS

Table 5.

Parameter

Rating

PVIN1/PVINSYS to AGND1/AGND2

−0.3 V to +16 V

PVIN2 to AGND1/AGND2

−0.3 V to +6.0 V

AGND1 to AGND2

−0.3 V to +0.3 V

PGND1 to AGND1/AGND2

−0.3 V to +0.3 V

PVOUT2 to AGND1/AGND2

−0.3 V to the lower of

(PVIN2 + 0.3 V) or +6.0 V

VFB2N to AGND1/AGND2/PGND1

−0.3 V to +0.3 V

VOUT1, VFB2P, EN1, EN2, SYNC, RT,

REFOUT, VBUF, VSET1, VSET2,

COMP1 to AGND1/AGND2

−0.3 V to the lower of (VREG

+ 0.3 V) or +6.0 V

SW1 to PGND1

−0.3 V to (PVIN1 + 0.3 V)

VREG, VREG_LDO to

AGND1/AGND2/PGND1/VFB2N

−0.3 V to the lower of

(PVINSYS + 0.3 V) or +6.0 V

VREG to VREG_LDO

−0.3 V to +0.3 V

Storage Temperature Range

−65°C to +150°C

Operating Junction Temperature

Range

−40°C to +125°C

Soldering Conditions

JEDEC J-STD-020

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

Thermal performance is directly linked to PCB design and

operating environment. Careful attention to PCB thermal

design is required.

Table 6. Thermal Resistance

Package Type

θJA1

θJC1

Unit

CP-32-7

46.91

20.95

°C/W

θJA and θJC are based on a 4-layer PCB (two signal and two power planes)

with nine thermal vias connecting the exposed pad to the ground plane as

recommended in the Layout Considerations section.
