MAINSLINK

Technical Specification:

Dimensions:

88 x 88 x 54mm (see page 3)

Storage Temperature:

-10 to +70

Operating Temperature:

0 to +50

Electrical Characteristics:

*MAINSLINK uses RF Solutions APLHA range of radio modules. For further transmission information see the relevant datasheet.

Min

Typical

Max

Units

Supply Voltage TX/RX:

100

230

250

Vac

Quiescent Current:

TX: (negligible @230V <0.1uA)

RX: (Relay not operating - negligible @230V

<0.1uA)

~

0.1

(relay

operating)

uA

mA

Operating Frequency*

869.50

MHz

Maximum switching load (RX)

1000

W

Time delay from Tx on switch to Rx Relay opera-

tion:

50

50

3000

mS

Time delay from Tx sw relax to Rx Relay release:

50

50

3000

mS

RF Solutions Ltd. Recycling Notice

Meets the following EC Directives:

DO NOT

Discard with normal waste, please recycle.

ROHS Directive 2002/95/EC

Specifies certain limits for hazardous substances.

WEEE Directive 2002/96/EC

Waste electrical & electronic equipment. This product

must be disposed of through a licensed WEEE collection

point. RF Solutions Ltd., fulfills its WEEE obligations by

membership of an approved compliance scheme.

Waste Batteries and Accumulators

Directive 2006/66/EC

Where batteries are fitted, before recycling the

product, the batteries must be

removed and disposed of at a licensed

collection point.

Environment Agency producer registration

number: WEE/JB0104WV.
