MB96340 Series

Document Number: 002-04579 Rev. *A

Page 90 of 109

3FF

3FE

3FD

004

003

002

001

AVRL

AVRH

AVRL

AVRH

+ 1

− 1

− 2

VOT (actual measurement value)

{1 LSB

× (N − 1)

+ VOT }

Actual conversion

characteristics

VFST (actual

measurement

value)

VNT (actual

measurement value)

Actual conversion

characteristics

Ideal characteristics

Actual conversion

characteristics

Actual conversion

characteristics

Ideal

characteristics

Analog input

VNT

(actual measurement value)

V (N + 1) T

(actual measurement

value)

Nonlinearity error

Differential nonlinearity error

Nonlinearity error of digital output N



1 LSB



VNT  {1 LSB  (N  1)  VOT}

1 LSB

[LSB]

Differential nonlinearity error of digital output N



V (N+1) T  VNT

1 LSB

 1LSB [LSB]

VFST  VOT

1022

[V]

N: A/D converter digital output value

VOT: Voltage at which digital output transits from “000H” to “001H.”

VFST: Voltage at which digital output transits from “3FEH” to “#FFH.”
