MB96340 Series

Document Number: 002-04579 Rev. *A

Page 67 of 109

Power supply

current in Timer

modes[1]

ICCTPLL

PLL Timer mode with CLKMC = 4MHz,

CLKPLL = 48MHz

(CLKRC and CLKSC stopped. Core volt-

age at 1.9V)

+25°C

1.6

Flash devices

+125°C

2.1

+25°C

1.6

MB96345/346

+125°C

2.1

ICCTMAIN

Main Timer mode with CLKMC = 4MHz,

SMCR:LPMSS = 0

(CLKPLL, CLKRC and CLKSC stopped.

Voltage regulator in high power mode)

+25°C

0.35

0.5

MB96F346/F347/F348

+125°C

0.85

3.3

+25°C

0.13

0.2

MB96F345

+125°C

0.63

+25°C

0.35

0.5

MB96345/346

+125°C

0.85

2.3

Main Timer mode with CLKMC = 4MHz,

SMCR:LPMSS = 1

(CLKPLL, CLKRC and CLKSC stopped.

Voltage regulator in low power mode)

+25°C

0.1

0.15

Flash devices

+125°C

0.6

2.9

+25°C

0.1

0.15

MB96345/346

+125°C

0.6

1.9

ICCTRCH

RC Timer mode with CLKRC = 2MHz,

SMCR:LPMSS = 0

(CLKMC, CLKPLL and CLKSC stopped.

Voltage regulator in high power mode)

+25°C

0.35

0.5

MB96F346/F347/F348

+125°C

0.85

3.3

+25°C

0.13

0.2

MB96F345

+125°C

0.63

+25°C

0.35

0.5

MB96345/346

+125°C

0.85

2.3

RC Timer mode with CLKRC = 2MHz,

SMCR:LPMSS = 1

(CLKMC, CLKPLL and CLKSC stopped.

Voltage regulator in low power mode)

+25°C

0.1

0.15

Flash devices

+125°C

0.6

2.9

+25°C

0.1

0.15

MB96345/346

+125°C

0.6

1.9

(TA = -40°C to 125°C, VCC = AVCC = 3.0V to 5.5V, VSS = AVSS = 0V)

Parameter

Symbol

Condition (at TA)

Value

Remarks

Typ

Max

Unit
