Configuration

• TNC Female Connector

• MIL-STD-348A

• 50 Ohms

• Straight Body Geometry

• RG58, RG303, RG141, PE-C195, PE-P195, LMR-

195, 0.195 inch Interface Type

• Crimp/Solder Attachment

• Bulkhead

Features

• Max. Operating Frequency 4 GHz

• Good VSWR of 1.5:1

• Gold Plated Brass Contact

• 30 µin minimum contact plating

Applications

• General Purpose Test

• Rack and Panel Mount Applications

• Custom Cable Assemblies

.

Description

Pasternack’s PE4151 TNC female bulkhead connector with crimp/solder attachment for RG58, RG303, RG141, PE-C195,

PE-P195, LMR-195 and 0.195 inch (.480 inch D hole) is part of our full line of RF components available for same-day shipping.

Our TNC female connector operates up to a maximum frequency of 4 GHz and offers good VSWR of 1.5:1. This TNC bulkhead

connector allows designers to create external connections on their product enclosures, and can be used in a variety of other

rack mount and panel mount applications.

Our TNC female bulkhead connector PE4151 datasheet specifications and drawing with dimensions are shown below in

this PDF. Pasternack’s broad catalog of RF, microwave and millimeter wave connectors allows designers to configure and

customize their signal connections however they like. Whether the need is to provide an I/O for a board design, or simply

create a custom cable assembly configuration, Pasternack has the right connector for the job. Pasternack can also expertly

build your custom cable assemblies for you and ship same-day.

Electrical Specifications

Description

Minimum

Typical

Maximum

Units

Frequency Range

DC

4

GHz

VSWR

1.5:1

Operating Voltage (AC)

500

Vrms

.

Mechanical Specifications

Size

Length

1.42 in [36.07 mm]

Width/Dia.

0.689 in [17.50 mm]

.

Weight

0.039 lbs [17.69 g]

.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: TNC Female Bulkhead Mount Connector Crimp/Solder Attachment for RG58, RG303, RG141,

PE-C195, PE-P195, LMR-195, 0.195 inch, .480 inch D Hole PE4151

PE4151 REV 1.1

TNC Female Bulkhead Mount Connector Crimp/Solder

Attachment for RG58, RG303, RG141, PE-C195, PE-

P195, LMR-195, 0.195 inch, .480 inch D Hole

RF Connectors Technical Data Sheet

PE4151
