Mitsubishi microcomputers

M16C / 62A Group

SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER

Serial I/O

107

Serial I/O

Serial I/O is configured as five channels: UART0, UART1, UART2, S I/O3 and S I/O4.

UART0 to 2

UART0, UART1 and UART2 each have an exclusive timer to generate a transfer clock, so they operate

independently of each other.

Figure 1.16.1 shows the block diagram of UART0, UART1 and UART2. Figures 1.16.2 and 1.16.3 show

the block diagram of the transmit/receive unit.

UARTi (i = 0 to 2) has two operation modes: a clock synchronous serial I/O mode and a clock asynchronous

serial I/O mode (UART mode). The contents of the serial I/O mode select bits (bits 0 to 2 at addresses

03A016, 03A816 and 037816) determine whether UARTi is used as a clock synchronous serial I/O or as a

UART. Although a few functions are different, UART0, UART1 and UART2 have almost the same functions.

UART2, in particular, is used for the SIM interface with some extra settings added in clock-asynchronous

serial I/O mode (Note). It also has the bus collision detection function that generates an interrupt request if

the TxD pin and the RxD pin are different in level.

Table 1.16.1 shows the comparison of functions of UART0 through UART2, and Figures 1.16.4 to 1.16.9

show the registers related to UARTi.

Note: SIM : Subscriber Identity Module

Note 1: Only when clock synchronous serial I/O mode.

Note 2: Only when clock synchronous serial I/O mode and 8-bit UART mode.

Note 3: Only when UART mode.

Note 4: Using for SIM interface.

UART0

UART1

UART2

Function

CLK polarity selection

Continuous receive mode selection

LSB first / MSB first selection

Impossible

Transfer clock output from multiple

pins selection

Impossible

Serial data logic switch

Impossible

Sleep mode selection

Impossible

TxD, RxD I/O polarity switch

Impossible

Possible

CMOS output

TxD, RxD port output format

CMOS output

N-channel open-drain

output

Impossible

Parity error signal output

Impossible

Bus collision detection

Impossible

Possible

(Note 1)

Possible

(Note 1)

Possible

(Note 1)

Possible

(Note 3)

Possible

(Note 1)

Possible

(Note 1)

Possible

(Note 1)

Possible

(Note 1)

Possible

(Note 3)

Possible

(Note 1)

Possible

(Note 2)

Possible

(Note 1)

Possible

(Note 4)

Possible

(Note 4)

Table 1.16.1. Comparison of functions of UART0 through UART2
