M30620FCAFP Datasheet(PDF) 1 Page - Mitsubishi Electric Semiconductor |
|
|
|||||||||||||||||||||||||||||
M30620FCAFP Datasheet(HTML) 1 Page - Mitsubishi Electric Semiconductor |
|
|
1 / 274 page  Mitsubishi microcomputers M16C / 62A Group SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER Description 1 ------Table of Contents------ Description The M16C/62A group of single-chip microcomputers are built using the high-performance silicon gate CMOS process using a M16C/60 Series CPU core and are packaged in a 100-pin plastic molded QFP. These single-chip microcomputers operate using sophisticated instructions featuring a high level of instruc- tion efficiency. With 1M bytes of address space, they are capable of executing instructions at high speed. They also feature a built-in multiplier and DMAC, making them ideal for controlling office, communications, industrial equipment, and other high-speed processing applications. The M16C/62A group includes a wide range of products with different internal memory types and sizes and various package types. Features • Memory capacity .................................. ROM (See Figure 1.1.4. ROM Expansion) RAM 3K to 20K bytes • Shortest instruction execution time ...... 62.5ns (f(XIN)=16MHZ, VCC=5V) 100ns (f(XIN)=10MHZ, VCC=3V, with software one-wait) : Mask ROM, flash memory 5V version • Supply voltage ..................................... 4.2V to 5.5V (f(XIN)=16MHZ, without software wait) : Mask ROM, flash memory 5V version 2.7V to 5.5V (f(XIN)=10MHZ with software one-wait) : Mask ROM, flash memory 5V version • Low power consumption ...................... 25.5mW ( f(XIN)=10MHZ, with software one-wait, VCC = 3V) • Interrupts .............................................. 25 internal and 8 external interrupt sources, 4 software interrupt sources; 7 levels (including key input interrupt) • Multifunction 16-bit timer ...................... 5 output timers + 6 input timers • Serial I/O .............................................. 5 channels (3 for UART or clock synchronous, 2 for clock synchro- nous) • DMAC .................................................. 2 channels (trigger: 24 sources) • A-D converter ....................................... 10 bits X 8 channels (Expandable up to 10 channels) • D-A converter ....................................... 8 bits X 2 channels • CRC calculation circuit ......................... 1 circuit • Watchdog timer .................................... 1 line • Programmable I/O ............................... 87 lines • Input port .............................................. _______ 1 line (P85 shared with NMI pin) • Memory expansion .............................. Available (to a maximum of 1M bytes) • Chip select output ................................ 4 lines • Clock generating circuit ....................... 2 built-in clock generation circuits (built-in feedback resistor, and external ceramic or quartz oscillator) Applications Audio, cameras, office equipment, communications equipment, portable equipment Timer ............................................................. 77 Serial I/O ..................................................... 107 A-D Converter ............................................. 148 D-A Converter ............................................. 158 CRC Calculation Circuit .............................. 160 Programmable I/O Ports ............................. 162 Electrical characteristic ............................... 173 Flash memory version ................................. 216 Central Processing Unit (CPU) ..................... 11 Reset ............................................................. 14 Processor Mode ............................................ 21 Clock Generating Circuit ............................... 35 Protection ...................................................... 44 Interrupts ....................................................... 45 Watchdog Timer ............................................ 65 DMAC ........................................................... 67 |
