Features:

1. Top view LED.

2. white SMT package.

3. Leadframe package with individual 4 pin.

4.Wide viewing angle.

5.Soldering methods:IR reflow soldering.

6.Feature of the device:more light due to higher optical efficiency;extremely

wide viewing angle;ideal for backlighting and coupling in light guide.

Descriptions:

The LURLVIR9553 SMD has wide viewing angle and optimized light coupling by

inter reflector,The low current requirement makes this device ideal for portable

equipment or any other application where power is at a premium.

Applications:

1. Telecommunication: indicator and backlighting in telephone and fax.

2. Indicators.

3. Switch lights.

Device Selection Guide:

PART NO. LURLVIR9553/R4

LIGITEK ELECTRONICS CO.,LTD.

Property of Ligitek Only

LURLVIR9553/R4

PART NO

COLOR

GaAlAs

Red

MATERIAL

Emitted

Water Clear

Lens

GaAlAs

Infrared

Page 1/12
