CS30
Electrical characteristics
18
Figure 6. Minimum common mode operating
voltage vs. temperature
Figure 7. Output stage low-state saturation
voltage versus output current (Vsense =-1 V)
Figure 8. Output stage high-state saturation
voltage versus output current
(Vsense =+1V)
Figure 9. Output short-circuit source current
versus temperature (Out pin connected to
ground)
Figure 10. Output short-circuit sink current
versus temperature (Out pin connected to VCC)
Figure 11. Output stage load regulation
