OMAP3530, OMAP3525
SPRS507H – FEBRUARY 2008 – REVISED OCTOBER 2013
www.ti.com
Figure 2-5. OMAP3530/25 Applications Processor CUS s-PBGA-N423 Package (Bottom View)
2.2
Pin Assignments
2.2.1
Pin Map (Top View)
The following pin maps show the top views of the 515-pin sPBGA package [CBB], the 515-pin sPBGA
package [CBC], and the 423-pin sPBGA package [CUS] pin assignments in four quadrants (A, B, C, and
D).
14
TERMINAL DESCRIPTION
Copyright © 2008–2013, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Links: OMAP3530 OMAP3525
