ZSLS7031 Datasheet
© 2016 Integrated Device Technology, Inc.
7
January 26, 2016
1.4
Typical Performance Characteristics Graphs
Figure 1.1 VIN vs. PF (Output: VOUT=40V, IOUT=0.45A)
Figure 1.2 VIN vs. IOUT (Output: target IOUT=0.45A,
VOUT=40V, without line compensation
circuit)
Figure 1.3 VIN vs. Efficiency (Output: VOUT=40V,
IOUT=0.45A)
Figure 1.4 VIN vs. IOUT (Output: target IOUT=0.45A,
VOUT=40V, with line compensation circuit)
