AD8556

Data Sheet

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Supply Voltage

6 V

Input Voltage

VSS − 0.3 V to VDD + 0.3 V

Differential Input Voltage1

±5.0 V

Output Short-Circuit Duration to

VSS or VDD

Indefinite

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +150°C

Junction Temperature Range

−65°C to +150°C

Lead Temperature

300°C

Differential input voltage is limited to ±5.0 V or ± the supply voltage,

whichever is less.

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

θJA is specified for the worst-case conditions, that is, a device

soldered in a circuit board for surface-mount packages.

Table 3. Thermal Resistance

Package Type

θJA1

θJC

Unit

8-Lead SOIC_N (R)

158

°C/W

16-Lead LFCSP_WQ (CP)

31.5

°C/W

θJA is specified for the worst-case conditions, that is, θJA is specified for device

soldered in circuit board for LFCSP_WQ package.

ESD CAUTION

Rev. B | Page 6 of 27
