Technical Data 10413

Effective August 2015

Supersedes July, 2015

BUSSMANN

SERIES

250V KWN-R and 600V KWS-R Class RK1 fuses

Catalog symbols:

• KWN-R-(amp) 250V

• KWS-R-(amp) 600V

Description:

250V KWN-R and 600V KWS-R fast-acting

Limitron™ fuses are UL Listed as Class RK1

fuses. They are dual voltage rated and can be

applied at 250Vac/dc and 600Vac/dc respectively

with interrupting ratings of 200kA AC and 20kA

DC.

Ratings

• Volts

• 250Vac/dc KWN-R

• 600Vac/dc KWS-R

• Amps 1-60A

• Interrupting rating

• 200kA AC

• 20kA DC

Agency information

• CE

• UL Listed, Std. 248-12, Class RK1, Guide JDDZ,

File E4273

• CSA Certified, C22.2 No. 248.12,

Class 1422-02, File 53787

250V KWN-R catalog numbers (amp)

KWN-R-1

KWN-R-15

KWN-R-50

KWN-R-3

KWN-R-20

KWN-R-60

KWN-R-5

KWN-R-25

KWN-R-6

KWN-R-30

KWN-R-10

KWN-R-40

600V KWS-R catalog numbers (amp)

KWS-R-1

KWS-R-15

KWS-R-40

KWS-R-3

KWS-R-20

KWS-R-50

KWS-R-5

KWS-R-25

KWS-R-60

KWS-R-6

KWS-R-30

KWS-R-10

KWS-R-35

KWN-R and KWS-R Carton quantity

Amp rating

Carton qty.

1–60

10
