SANGDEST

MICROELECTRONICS

Technical Data

Green Products

Data Sheet N1169, Rev. -

• Weiqi Street, Airport Development Zone, Jiangning District, Nanjing, China 211113

(86) 25-87123907

•

• FAX (86) 25-87123900 • World Wide Web Site - http://www.sangdest.com.cn • E-Mail Address - sales@ sangdest.com.cn •

129NQ...R-1 SERIES

Maximum Ratings:

Characteristics

Symbol

Condition

Max.

Units

Peak Repetitive Reverse Voltage

Working Peak Reverse Voltage

DC Blocking Voltage

-

135

129NQ135(R)-1

V

150

129NQ150(R)-1

Max. Average Forward Current

50% duty cycle

wave form

120

A

Max. Peak One Cycle Non-

Repetitive Surge Current

(per leg)

8.3 ms, half Sine pulse

1140

A

Electrical Characteristics:

Characteristics

Symbol

Condition

Max.

Units

Max. Forward Voltage Drop*

1.07

V

0.74

V

Max. Reverse Current (per

leg) *

3

mA

45

mA

Max. Junction Capacitance

(per leg)

3000

pF

Typical Series Inductance

(per leg)

Measured lead to lead 5 mm

from package body

6.0

nH

Max. Voltage Rate of Change

dv/dt

-

10,000

V/

μs

Thermal-Mechanical Specifications:

Characteristics

Symbol

Condition

Specification

Units

Max. Junction Temperature

-

-55 to +175

°C

Max. Storage Temperature

-

-55 to +175

°C

Maximum Thermal

Resistance Junction to Case

DC operation

0.40

°C/W

Typical Thermal Resistance,

case to Heat Sink

Mounting surface, smooth

and greased

0.15

°C/W

Mounting Torque

Non-lubricated threads

Mounting

Torque

23(min)

29(max)

Kg-cm

Terminal

Torque

35(min)

46(max)

Approximate Weight

wt

-

25.6

g

Case Style

PRM1-1
