ADPD2214
Data Sheet
Rev. 0 | Page 12 of 13
EVALUATION BOARD SCHEMATIC AND LAYOUT
Figure 15 shows the evaluation board schematic. Figure 13 and
Figure 14 show the evaluation board layout for the top and
bottom layers, respectively.
Figure 13. ADPD2214 Evaluation Board Top Layer
Figure 14. ADPD2214 Evaluation Board Bottom Layer
Figure 15. ADPD2214 Evaluation Board Schematic (Do Not Install C3C)
EVALZ-ADPD2214
U1C
1
3
5
4
7
10
PWDN
NIC
NIC
VCC
GND
NIC
2
8
9
NIC
VCC
PWDN
GND
OUT
NIC
NIC
OUT
EPAD
R1C
100kΩ
R2C
100kΩ
C2C
1µF
C3C
0.01µF
DNI
DNI
C1C
0.01µF
6
